LM100EVF

Evolution

Garage door opener

LM100EVF

The fast garage door opener with more power for larger size doors, LM100EVF

Super-quiet and fast-running garage door opener including two multi-frequency transmitters, wireless radio wall control and a modern, powerful LED lighting system. For doors with door weights up to 150 kg. Compatible with MyQ smart-home technology.

  • Stay connected with MyQ

    Stay connected with MyQ

    With MyQ, you can monitor and control your garage door, using your smartphone, tablet or computer from wherever you happen to be.

  • Smart radio technology

    Smart radio technology

    Evolution operators are equipped with the best reliable radio that is a bi-directional radio. They don't only receive signal, they also sends signals back.

  • Strength in silence

    Strength in silence

    The quiet operation of our garage door openers is unparalleled.

  • High running speed

    High running speed

    The running speed with a maximum of 200 mm/s is an important safety and comfort feature.

  • Up to 8 years motor warranty

    Up to 8 years motor warranty

    The long-time warranty demonstrates that LiftMaster provides premium quality products

  • Economic and environmentally friendly

    Economic and environmentally friendly

    The extremely low standby energy consumption is good for the environment and your pocket.

  • Long-lasting LEDs

    Long-lasting LEDs

    Immediate brightness, low CO2 emissions and avoidance of heavy metals and mercury in manufacturing.

  • Quickly installed

    Quickly installed

    Simple installation with standard tools.

Voltage IN 230-240 V, 50/60 Hz
Motor voltage 24V DC
Max pull force 1000 N
Stand-by power 0,8 W
Drive type Belt
Gate height Adjustable up to 2,25 m or up to 4 m with appropriate extension
Speed
Lighting LED turns on with activation, turns off 2.5 minutes after operation
Obstacle detection Automatic
Force setting Automatic
Over voltage protection Transformer overload protection
Operating temperature -30°C bis +55°C
Limit Switch Electronic
Max door area
Max door width 5,75 m
Max door weight 150 Kg
Headroom required min. 35 mm
Weight 12 Kg
Memory registers 180
Radio 433 MHz + 868 MHz
Further features Soft-start and soft-stop, automatic close
MyQ smartphone combatible Yes (optional Internet Gateway 828EV required)
Safety class TÜV-tested to meet EN12453. For doors up to 150 kg
Motor warranty 8 Years*
